linear algebra crash course / review

COS 350 - Computer Graphics

notation

Matrix and Vector Matrix notation

\[ M = \mat{ m_{11} & m_{12} & \ldots & m_{1N} \\ m_{21} & m_{22} & \ldots & m_{2N} \\ \vdots & \vdots & \ddots & \vdots \\ m_{M1} & m_{M2} & \ldots & m_{MN} \\ } = \mat{m_{ij}} \]

\[\v = \mat{v_1 \\ \vdots \\ v_M} = \mat{v_1 & \ldots & v_M}^T = \left( v_1, \ldots, v_M \right)\]

vectors use column matrix or ordered tuple
will use decorations to denote different "types" of vectors

linear algebra crash course / review

vector representation

vectors

2D/3D objects represented using mathematical vectors

point: location in space
- \( \point{p}_\text{2D} = (p_x, p_y)\), \(\point{p}_\text{3D} = (p_x, p_y, p_z) \)

vector: direction and magnitude
- \( \v_\text{2D} = (v_x, v_y)\), \(\v_\text{3D} = (v_x, v_y, v_z) \)
- on board, may use: \( \overset{\rightharpoonup}{\v} \)

direction: vector with unit magnitude
- \( \hat{\d}_\text{2D} = (d_x, d_y)\), where \(d_x^2 + d_y^2 = 1^2 \)
- \( \hat{\d}_\text{3D} = (d_x, d_y, d_z)\), where \(d_x^2 + d_y^2 + d_z^2 = 1^2 \)
Note: all objects are defined with respect to a frame (discussed soon)

points vs vectors/directions (vs normals)

Although we represent points in vector notation, points and vectors/directions are very different types, and they should be treated differently.

There are ways to distinguish between point and vector types, which we will get to.

But know that most graphics systems or game engines simply use vector notation for all, and it is up to you (the coder) to know how to handle everything correctly.

Also, there is one other vector-like type that we will introduce later which is different from points and vectors: normals.

vector/point operations

addition: component-wise addition

\[\u + \v = \mat{u_1 + v_1 \\ \vdots \\ u_M + v_M}\]

Types:

\(\point{p} + \v = \point{q}\)	point + vector = point
\(\x + \y = \u\)	vector + vector = vector

vector/point operations

subtraction: component-wise substraction

\[\u - \v = \mat{u_1 - v_1 \\ \vdots \\ u_M - v_M}\]

Types:

\(\point{p} - \v = \point{q}\)	point - vector = point
\(\x - \y = \u\)	vector - vector = vector
\(\point{p} - \point{q} = \v\)	point - point = vector

Note: difference of two points is vector from 2nd point to 1st ponit

vector/point operations

Note: adding two points does not make sense, but can be useful or convenient. For example, compute midpoint of \(\point{p}\) and \(\point{q}\):

incorrect:	\((\point{p} + \point{q}) / 2\)
correct:	\(\point{p} + (\point{q} - \point{p}) / 2\)

both forms are mathematically equivalent, but latter makes sense

CAUTION: notation is often abused, especially in systems that make no distinction between vectors and points

vector/point operations

scaling: magnitude multiplication

\[\alpha\v = (\alpha)(\v) = \mat{\alpha v_1 \\ \alpha v_2}\]

result is vector
scaling vector by scalar magnifies the magnitude
not correct, but useful: scaling point pushes point away/toward origin

Special cases:

scaling by \(-1\) will reverse dir of vector and keep its mag
scaling by \(0\) will result in 0-vector (undefined dir, \(0\) mag)

vector/point operations

dot product: one way of "multiplying" two vectors

\[\u \* \v = \sum_i u_iv_i = u_1v_1 + \ldots + u_Mv_M = ||\u||\ ||\v||\ \ct\]

where \(\theta\) is angle between \(\u\) and \(\v\)
result is scalar
when \(\u\) and \(\v\) are orthogonal/perpendicular, \(\u \* \v\) results in \(0\)

Note: dot product uses a centered dot, which is commonly used when multiplying two scalars (ex: \(2 \cdot 3 \equiv 2 * 3\)). If you represent a scalar as a 1D vector, and then the results are exactly as expected

vector/point operations

cross product: another way of "multiplying" vectors

\[\u \xx \v = \mat{u_2v_3 - u_3v_2 \\ u_3v_1 - u_1v_3 \\ u_1v_2 - u_2v_1}\]

defined only for 3D vectors
result vector
- has direction orthogonal to both input vectors, RHR
- has length equal to \(||\u||\ ||\v||\ \st\) where \(\theta\) is angle between \(\u\) and \(\v\)
many other useful properties!

vector/point operations

component-wise product: yet another way of "multiplying" vectors

\[ \vector{a} * \vector{b} = \mat{a_1 \\ \vdots \\ a_M} * \mat{b_1 \\ \vdots \\ b_M} = \mat{a_1 * b_1 \\ \vdots \\ a_M * b_M} \]

result vector
most of the times when you "multiply" two vectors, this is not the operation you will use
except if the vectors are representing colors (r,g,b)

vector/point operations

length: magnitude of vector

\[||\v|| = \sqrt{\sum_i v_i^2} = \sqrt{v_1^2 + \ldots + v_M^2} = \sqrt{\v \* \v}\]

result is scalar
will sometimes simplify \(||\v||\) as \(|\v|\) (not absolute value)

Notes:

When representing a scalar in vector notation, the length is equal to the absolute value of the scalar.
Technically, square root returns two values (positive and negative), but we will ignore the negative values for now.
The equation above is the usual way of computing length/magnitude, but there are other ways...

[ absolute-value norm ]

vector/point operations #

L¹ norm or Manhattan norm or Taxicab norm

\[||\v||_1 = \sum_i |v_i| = |v_1| + \ldots + |v_M|\]

L² norm or Euclidean norm (previous slide)

\[||\v||_2 = \sqrt{\sum_i v_i^2} = \sqrt{v_1^2 + \ldots + v_M^2} = \sqrt{\v \* \v}\]

L^∞ norm or Uniform norm or Maximum norm

\[||\v||_\infty = \max_i |v_i| = \max(|v_1|, \ldots, |v_M|)\]

[ Taxicab, Euclidean, Uniform, image ]

vector/point operations

normalize: a function that returns the direction of a given vector

\[\mathit{norm}(\v^+) = \frac{\v^+}{||\v^+||} = \hat{\v}\]

input: any non-zero vector (\(\mathit{norm}\) is undefined on 0-vector)
output: direction in same direction as given vector
recall \(|| \direction{v} || = 1\)

quiz: vector/point operations

[ live view, card view ]

Given:

\[ \u = \mat{ 2 \\ 3 } \qquad \v = \mat{ 4 \\ -1 }\]

What is the result of \(\u + \v\)?

\(8\)
\(\mat{6 \\ 2}\)
\(\mat{2 & 4 \\ 3 & -1}\)
\(\mat{6 & 2}\)

quiz: vector/point operations

[ live view, card view ]

Given:

\[ \u = \mat{2 \\ 3} \qquad \alpha = 4 \]

What is the result of \(\alpha \u\)?

\(20\)
\(\mat{8 \\ 3 }\)
\(\mat{8 \\ 12}\)
\(\mat{2 \\ 12}\)

linear algebra crash course / review

matrix representation

matrix operations

addition

\[T = M + N\]

\[\mat{t_{ij}} = \mat{m_{ij} + n_{ij}}\]

scalar multiplication

\[T = \alpha M\]

\[\mat{t_{ij}} = \mat{\alpha m_{ij}}\]

matrix operations

matrix-matrix multiplication

row-column multiplication
associative, not commutative

\[T = MN = \mat{t_{ij}} = \mat{\sum_k m_{ik} n_{kj}}\]

\[\mat{\color{red}{t_{11}} & t_{12} \\ t_{21} & t_{22}} = \mat{\color{red}{m_{11}} & \color{red}{m_{12}} \\ m_{21} & m_{22}} \mat{\color{red}{n_{11}} & n_{12} \\ \color{red}{n_{21}} & n_{22}}\]

\[\begin{array}{rcl} \color{red}{t_{11}} & \color{red}{=} & \color{red}{m_{11} \cdot n_{11} + m_{12} \cdot n_{21}} \\ t_{12} & = & m_{11} \cdot n_{12} + m_{12} \cdot n_{22} \\ t_{21} & = & m_{21} \cdot n_{11} + m_{22} \cdot n_{21} \\ t_{22} & = & m_{21} \cdot n_{12} + m_{22} \cdot n_{22} \\ \end{array}\]

\[\mat{t_{11} & \color{red}{t_{12}} \\ t_{21} & t_{22}} = \mat{\color{red}{m_{11}} & \color{red}{m_{12}} \\ m_{21} & m_{22}} \mat{n_{11} & \color{red}{n_{12}} \\ n_{21} & \color{red}{n_{22}}}\]

\[\begin{array}{rcl} t_{11} & = & m_{11} \cdot n_{11} + m_{12} \cdot n_{21} \\ \color{red}{t_{12}} & \color{red}{=} & \color{red}{m_{11} \cdot n_{12} + m_{12} \cdot n_{22}} \\ t_{21} & = & m_{21} \cdot n_{11} + m_{22} \cdot n_{21} \\ t_{22} & = & m_{21} \cdot n_{12} + m_{22} \cdot n_{22} \\ \end{array}\]

\[\mat{t_{11} & t_{12} \\ \color{red}{t_{21}} & t_{22}} = \mat{m_{11} & m_{12} \\ \color{red}{m_{21}} & \color{red}{m_{22}}} \mat{\color{red}{n_{11}} & n_{12} \\ \color{red}{n_{21}} & n_{22}}\]

\[\begin{array}{rcl} t_{11} & = & m_{11} \cdot n_{11} + m_{12} \cdot n_{21} \\ t_{12} & = & m_{11} \cdot n_{12} + m_{12} \cdot n_{22} \\ \color{red}{t_{21}} & \color{red}{=} & \color{red}{m_{21} \cdot n_{11} + m_{22} \cdot n_{21}} \\ t_{22} & = & m_{21} \cdot n_{12} + m_{22} \cdot n_{22} \\ \end{array}\]

\[\mat{t_{11} & t_{12} \\ t_{21} & \color{red}{t_{22}}} = \mat{m_{11} & m_{12} \\ \color{red}{m_{21}} & \color{red}{m_{22}}} \mat{n_{11} & \color{red}{n_{12}} \\ n_{21} & \color{red}{n_{22}}}\]

\[\begin{array}{rcl} t_{11} & = & m_{11} \cdot n_{11} + m_{12} \cdot n_{21} \\ t_{12} & = & m_{11} \cdot n_{12} + m_{12} \cdot n_{22} \\ t_{21} & = & m_{21} \cdot n_{11} + m_{22} \cdot n_{21} \\ \color{red}{t_{22}} & \color{red}{=} & \color{red}{m_{21} \cdot n_{12} + m_{22} \cdot n_{22}} \\ \end{array}\]

matrix operations

matrix-vector multiplication

treat vector as column matrix
row-column multiplication

\[\u = M\v\]

\[\mat{\color{red}{u_{1}} \\ u_{2}} = \mat{\color{red}{m_{11}} & \color{red}{m_{12}} \\ m_{21} & m_{22}} \mat{\color{red}{v_{1}} \\ \color{red}{v_{2}}}\]

matrix operations

transpose

flip along diagonal

\[T = M^T\]

\[\mat{t_{ij}} = \mat{m_{ji}}\]

inverse

important: not all matrices have an inverse
we will not compute inverse directly (expensive, can be numerically unstable)

\[T = M^{-1}, \quad MT = M M^{-1} = M^{-1} M = I\]

special matrices

identity matrix

invariant for multiplication

\[I = \mat{i_{ij}} = \def{}\]

\[I = \mat{1 & 0 \\ 0 & 1}\]

\[\forall M : M = MI = IM\]

special matrices

zero matrix

invariant for addition

\[O = \mat{i_{ij}} = 0\]

\[O = \mat{0 & 0 \\ 0 & 0}\]

\[\forall M : M = M + O = O + M\]

matrix operation properties

linearity of multiplication and addition

\[\alpha (A + B) = \alpha A + \alpha B\]

\[M(\alpha A + \beta B) = \alpha MA + \beta MB\]

associativity of multiplication

\[A(BC) = (AB)C\]

matrix operation properties

transpose and inverse of multiplication

\[(AB)^T = B^T A^T\]

\[(AB)^{-1} = B^{-1} A^{-1}\]

quiz: matrix operations

[ live view, card view ]

What is the result of \(AB\) if... ?

\[ A = \mat{ 1 & 2 \\ 3 & 4 \\ 5 & 6 } \qquad B = \mat{ 2 \\ 0 }\]

\(\mat{2 \\ 6 \\ 10}\)
\(\mat{2 & 4 \\ 6 & 8 \\ 10 & 12}\)
\(\mat{2 & 4}\)
Cannot multiply \(A\) and \(B\) (incompatible sizes)
